Havells EURO-II 100A DP C-Curve MCB – 10kA, 240/415V | DHMJCDPF100
Product Description
The Havells EURO-II 100A DP MCB is a higher-rating Double Pole Miniature Circuit Breaker designed for overcurrent and short-circuit protection in compatible electrical distribution systems.
This model has a 100 Amp rated current and C-curve tripping characteristic. Havells officially lists its higher-rating 80A–125A C-Series MCBs in accordance with IEC 60947-2, rated for 240/415V AC, 50Hz with a 10kA short-circuit breaking capacity. The official Havells catalogue identifies the 100A Double Pole variant by catalogue number DHMJCDPF100. Havells Power Plus
The Double Pole (DP) configuration provides simultaneous switching of two poles and is intended for compatible electrical installations where higher-current circuit protection is required. Its C-curve characteristic makes the range suitable for circuits where moderate starting or inrush currents may occur, subject to correct circuit design and protection coordination.
Key Specifications
- Brand: Havells
- Series: EURO-II Higher Rating MCB
- Product Type: Miniature Circuit Breaker
- Rated Current: 100A
- Number of Poles: 2 Pole / DP
- Trip Curve: C Curve
- Rated Voltage: 240/415V AC
- Frequency: 50Hz
- Breaking Capacity: 10kA
- Standard: IEC 60947-2
- Catalogue No.: DHMJCDPF100
- HSN Code: 8536 Havells Power Plus
Available at City Lighting And Electricals, Bemina, Srinagar, Kashmir for residential, commercial, contractor and project electrical requirements.
